Specs
435i, 16" 0.325" mini, Standard, SP21G 970 79 38‑24 | |
|---|---|
Battery | |
Battery ECO system | Husqvarna BLi-X 36 V |
435i, 16" 0.325" mini, Standard, SP21G 970 79 38‑24 | |
|---|---|
Engine | |
Output shaft power1 | 2.4 hp |
Battery voltage | 40 V |
Chain speed at max power | 68.93 fts |
Battery chemistry | Li-Ion |
Motor type | BLDC (brushless) |
Oil pump capacity, max | 0 ml/min |
Oil pump capacity, min | 0 ml/min |
Oil pump type | Automatic, gear driven |
435i, 16" 0.325" mini, Standard, SP21G 970 79 38‑24 | |
|---|---|
Equipment | |
Recommended bar length, min | 14 in |
Pitch | .325" mini |
Recommended bar length, max | 16 in |
Chain type | SP21G |
Battery | Not included |
Bar length (inch) | 16 in |
Sprocket type | Spur 7 |
Gauge | .043" |
435i, 16" 0.325" mini, Standard, SP21G 970 79 38‑24 | |
|---|---|
Dimensions | |
Weight (excl. battery and cutting equipment) | 5.95 lbs |
435i, 16" 0.325" mini, Standard, SP21G 970 79 38‑24 | |
|---|---|
Sound and noise | |
Sound pressure level at operators ear | 90 dB(A) |
Sound power level, guaranteed (LWA) | 103 dB(A) |
Sound power level, measured | 101 dB(A) |
435i, 16" 0.325" mini, Standard, SP21G 970 79 38‑24 | |
|---|---|
Vibration | |
Equivalent vibration level (ahv, eq) rear handle | 2.7 m/s² |
Equivalent vibration level (ahv, eq) front handle | 3.5 m/s² |
435i, 16" 0.325" mini, Standard, SP21G 970 79 38‑24 | |
|---|---|
Lubricant | |
Oil tank volume | 0.38 US pint |
