Specs
Engine
Cylinder displacement
60.3 cm³
Cylinder displacement
3.68 cu.inch
Power output
3.62 hp
Maximum power speed
9000 rpm
Fuel tank volume
0.9 US pint
Fuel consumption
437 g/kWh
Idling speed
2700 rpm
Spark plug
Champion RCJ7Y, NGK BPMR7A
Electrode gap
0.02 in
Torque, max.
3.4 Nm
Equipment
Recommended bar length, max
24 in
Recommended bar length, min
13 in
Dimensions
Weight (excl. cutting equipment)
13.2 lbs
Product Size, LxWxH
16.9×8.8×11.8 in
Limited Warranty
Homeowner Warranty
2 Years
Commercial Warranty
90 Days
Lubricant
Oil tank volume
0.7 US pint
Oil pump type
Automatic
Oil pump capacity Max
17 ml/min
Oil pump capacity Min
6 ml/min
Overall dimensions
Weight (excl. cutting equipment)
13.2 lbs
Sound and Noise
Sound power level, guaranteed (LWA)
114 dB(A)
Sound power level, measured
112 dB(A)
Sound pressure level at operators ear
104 dB(A)
Vibration
Equivalent vibration level (ahv, eq) front handle
3.8 m/s²
Equivalent vibration level (ahv, eq) rear handle
6.9 m/s²
