Specs
525HF3SArt no: 967 20 75‑01 | ||
|---|---|---|
| Capacity | 525HF3S Art no: 967 20 75‑01 | 525HF3S Art no: 967 20 75‑02 |
| Recommended maximum twig diameter | 0.94 in | 0.94 in |
| Cutting speed | 4,339 cut/min | 4,339 cut/min |
| Engine | ||
| Cylinder displacement | 1.55 cu.inch | 1.55 cu.inch |
| Power output | 1.21 hp | 1.21 hp |
| Maximum power speed | 8,500 rpm | 8,500 rpm |
| Fuel tank volume | 17.25 fl oz | 17.25 fl oz |
| Fuel consumption | 870.81 lbs/h | 870.81 lbs/h |
| Idling speed | 3,000 rpm | 3,000 rpm |
| Spark plug | NGK BPM8Y | NGK BPM8Y |
| Electrode gap | 0.03 in | 0.03 in |
| Equipment | ||
| Knife adjustment range, up/down Down | 0 ° | 0 ° |
| Knife adjustment range, up/down Up | 0 ° | 0 ° |
| Knife length | 25.59 in | 25.59 in |
| Teeth opening | 1.18 in | 1.18 in |
| Dimensions | ||
| Full length, including cutting equipment | 75.6 in | 75.6 in |
| Sound and Noise | ||
| Sound power level, guaranteed (LWA) | 105 dB(A) | 105 dB(A) |
| Sound pressure level at operators ear | 92 dB(A) | 92 dB(A) |
| Transmission | ||
| Gear ratio | 1 | 1 |
