Specs
Engine
Cylinder displacement
50.1 cm³
Cylinder displacement
3.06 cu.inch
Power output
4 hp
Maximum power speed
10200 rpm
Fuel tank volume
1.12 US pint
Fuel consumption
432 g/kWh
Idling speed
2800 rpm
Spark plug
NGK CMR6H
Electrode gap
0.02 in
Torque, max.
3.15 Nm
Equipment
Recommended bar length, max
20 in
Recommended bar length, min
13 in
Dimensions
Weight (excl. cutting equipment)
11.7 lbs
Product Size, LxWxH
17.3×8.7×11 in
Limited Warranty
Homeowner Warranty
2 Years
Commercial Warranty
1 Year
Lubricant
Oil tank volume
0.68 US pint
Oil pump type
Adjustable flow, no flow at idle
Overall dimensions
Weight (excl. cutting equipment)
11.7 lbs
Sound and Noise
Sound power level, guaranteed (LWA)
117 dB(A)
Sound power level, measured
115 dB(A)
Sound pressure level at operators ear
107 dB(A)
Vibration
Equivalent vibration level (ahv, eq) front handle
3.3 m/s²
Equivalent vibration level (ahv, eq) rear handle
4.9 m/s²
