Specs
Engine
<!-- -->
Engine Name
Vanguard Big Block EFI/ETC with Oil Guard
Horsepower
40HP
Fuel Capacity
16gal
Drive Line
<!-- -->
Hydraulic Drive
Parker HTG Transaxles - 16cc Drive Motors
Hydraulic Drive Torque
Continuous - 498 ft-lb | Max Torque - 587 ft-lb
Hydro Drive Maintenance
1000 Hours Between Oil Changes
Drive Tires
24x14-R12 Michelin Tweels®
Front Tires
13x6.5-R6 Michelin Tweels®
Wheels Type
Michelin Tweels®
Speed (F/R)
Forward - Up to 15mph | Reverse - Up to 6mph
Features
<!-- -->
Seat
Supreme Custom Blackout Seat - Adjustable TecsPak Elastomer supports - 360 degree floating seat platform
Steering Levers
Soft-Touch Knobs to Adjust Forward and Back. Adjustable Up and Down
Control Panel LCD Display
Engine Hour Meter - Mower Deck Hour Meter - Tachometer - Low Level Warning Volt Meter - Time Between Oil Change Countdown - Fault Codes
Control Panel LED Warning Indicators
Parking Brake Set - Drive Levers - Operator Present - PTO - Low/Hi Battery Volts - Low Oil PSI
Ignition
Keyless, Personal Code activated
Auxiliary Power
12v Outlet
Storage
Phone Holder, Cup Holder, and Deep Storage Tray
Hitch
2” Rear Receiver Standard
Cutting Deck
<!-- -->
Deck Sizes
61", 72"
Deck Depth
6" Deep, Reinforced 7 Gauge Full-Floating Deck
Deck Lift
Foot Operated with Shock Assist
Deck Adjustment
Magnetic Pin Height Adjustment
Cut Height
1" to 5" with 15 Cut Heights
Blade Spindles
Cast Aluminum, No Maintenance/Sealed Bearings
Parking Brake
Foot Operated
Frame
1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
Measurements
<!-- -->
Width
61” Deck - 62.5” Wide | 72” Deck - 73.5” Wide
Weight
1310lbs
Length
84”
Height
75" with ROPS Up - 54" with Folding ROPS Down
Warranty
<!-- -->
Engine Warranty
3 Year
Full Warranty
3 Year / 500 Hour Residential - 2 Year / Unlimited Hour Commercial - 120 Day Belt Warranty
Deck Warranty
Lifetime on the leading edge
Hydraulic Drive Warranty
3 Year / 1500 Hour
Control Panel Warranty
3 Year
