Specs
525RXArt no: 967 17 57‑01 |
||
|---|---|---|
| Engine |
525RX
Art no: 967 17 57‑01
|
525RX
Art no: 967 17 57‑02
|
| Torque, max. | 1.2 Nm | 1.2 Nm |
| Torque, max. at rpm | 6,000 rpm | 6,000 rpm |
| Cylinder displacement | 1.55 cu.inch | 1.55 cu.inch |
| Power output | 1.34 hp | 1.34 hp |
| Maximum power speed | 8,500 rpm | 8,500 rpm |
| Fuel tank volume | 17.25 fl oz | 17.25 fl oz |
| Fuel consumption | 600 g/kWh | 600 g/kWh |
| Idling speed | 3,000 rpm | 3,000 rpm |
| Electrode gap | 0.03 in | 0.03 in |
| Clutch engagement speed (±120) | 4,000 rpm | 4,000 rpm |
| Maximum rpm output shaft | 6,500 rpm | 6,500 rpm |
| Transmission | ||
| Gear ratio | 19 | 19 |
| Drive gear angle | 30 ° | 30 ° |
| Dimensions | ||
| Weight (excl. cutting equipment) | 10.8 lbs | 10.8 lbs |
| Tube length | 58.386 in | 58.386 in |
| Tube diameter | 0.94 in | 0.94 in |
| Equipment | ||
| Grass blade | Grass 255-4 | Grass 255-4 |
| Harness | Balance 35 | Balance 35 |
| Trimmer head | T35 M10 | T35 M10 |
| Saw blade | Not included | Not included |
| Lubricant | ||
| Lubricant type | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 |
| Sound and Noise | ||
| Sound power level, guaranteed (LWA) | 106 dB(A) | 106 dB(A) |
| Sound power level, measured | 104 dB(A) | 104 dB(A) |
| Sound pressure level at operators ear | 93 dB(A) | 93 dB(A) |
| Emission | ||
| Exhaust emissions (HC average) | 32.47 g/kWh | |
| Exhaust emissions (HC average) | 32.47 g/kWh | |
| Exhaust emissions (CO average) | 87.57 g/kWh | 87.57 g/kWh |
| Exhaust emissions (CO average) | 254.3 g/kWh | |
| Exhaust emissions (CO average) | 254.3 g/kWh | |
| Exhaust emissions (NOx average) | 0.56 g/kWh | 0.56 g/kWh |
| Exhaust emissions (NOx average) | 0.2 g/kWh | |
| Exhaust emissions (NOx average) | 0.2 g/kWh | |
| Vibration | ||
| Equivalent vibration level (ahv, eq) front handle | 2.1 m/s² | 2.1 m/s² |
| Equivalent vibration level (ahv, eq) rear handle | 2.3 m/s² | 2.3 m/s² |
