Specs
20" SN .325" 1,3 mm SP33G SKU: 967 69 06‑02 | |||||||
---|---|---|---|---|---|---|---|
Engine | 20" SN .325" 1,3 mm SP33G SKU: 967 69 06‑02 | 16" SN .325" 1,5 mm S35G SKU: 967 69 06‑16 | 18" SN .325" 1,5 mm S35G SKU: 967 69 06‑18 | 20" SN .325" 1,3 mm SP33G SKU: 967 69 06‑28 | 16" SN .325" 1,3 mm SP33G SKU: 967 69 06‑36 | 18" SN .325" 1,3 mm SP33G SKU: 967 69 06‑38 | 20" SN .325" 1,3 mm SP33G SKU: 967 69 06‑40 |
Chain speed at max power | 62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts | 62.7 fts |
Cylinder displacement | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ | 50.1 cm³ |
Output shaft power1 | 3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp | 3.6 hp |
Torque, max. | 2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm | 2.95 Nm |
Torque, max. at rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm | 7,200 rpm |
Clutch engagement speed (±120) | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm | 3,900 rpm |
Electrode gap | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in |
Idling speed | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm |
Ignition module air gap | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in |
Maximum power speed | 9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm | 9,900 rpm |
Oil pump type | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle | Adjustable flow, no flow at idle |
Spark Plug | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H |
Equipment | |||||||
Recommended bar length, min | 13 in | 13 in | 13 in | 13 in | 13 in | 13 in | 13 in |
Pitch | .325" | .325" | .325" | .325" | .325" | .325" | .325" |
Recommended bar length, max | 20 in | 20 in | 20 in | 20 in | 20 in | 20 in | 20 in |
Chain type | SP33G | S35G | S35G | SP33G | SP33G | SP33G | SP33G |
Bar length | 50 cm | 40 cm | 45 cm | 50 cm | 40 cm | 45 cm | 50 cm |
Bar length (inch) | 20 in | 16 in | 18 in | 20 in | 16 in | 18 in | 20 in |
Sprocket type | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 |
Gauge | .050" | .058" | .058" | .050" | .050" | .050" | .050" |
Dimensions | |||||||
Weight (excl. cutting equipment) | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs | 11.7 lbs |
Sound and noise | |||||||
Sound pressure level at operators ear | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) |
Sound power level, guaranteed (LWA) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) | 115 dB(A) |
Sound power level, measured | 113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) | 113 dB(A) |
Vibration | |||||||
Equivalent vibration level (ahv, eq) rear handle | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² | 4.6 m/s² |
Equivalent vibration level (ahv, eq) front handle | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² | 4 m/s² |
Lubricant | |||||||
Oil tank volume | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 |
Emission | |||||||
Exhaust emissions (CO₂ EU V)2 | 844 g/kWh | 844 g/kWh | 844 g/kWh | 844 g/kWh | 844 g/kWh | 844 g/kWh | 844 g/kWh |
