Specs
Engine
Cylinder displacement
35.2 cm³
Cylinder displacement
2.15 cu.inch
Power output
2.01 hp
Maximum power speed
10000 rpm
Fuel tank volume
0.55 US pint
Fuel consumption
408 g/kWh
Idling speed
2900 rpm
Spark plug
NGK CMR6H
Electrode gap
0.03 in
Torque, max.
1.57 Nm
Equipment
Recommended bar length, max
14 in
Recommended bar length, min
12 in
Dimensions
Weight (excl. cutting equipment)
7.5 lbs
Product Size, LxWxH
12.01×9.65×9.1 in
Limited Warranty
Homeowner Warranty
2 Years
Commercial Warranty
90 Days
Lubricant
Oil tank volume
0.36 US pint
Oil pump type
Automatic
Oil pump capacity Max
9 ml/min
Oil pump capacity Min
3 ml/min
Overall dimensions
Weight (excl. cutting equipment)
7.5 lbs
Sound and Noise
Sound power level, guaranteed (LWA)
114 dB(A)
Sound power level, measured
112 dB(A)
Sound pressure level at operators ear
103 dB(A)
Vibration
Equivalent vibration level (ahv, eq) front handle
3.6 m/s²
Equivalent vibration level (ahv, eq) rear handle
3.9 m/s²
