Specs
Engine
<!-- -->
Engine Name
Kawasaki FT703V
Horsepower
24HP
Fuel Capacity
9.5gal
Drive Line
<!-- -->
Hydraulic Drive
Tuff Torq TZT - 13cc
Hydraulic Drive Torque
Continuous - 262 ft-lb | Max Torque - 406 ft-lb
Hydro Drive Maintenance
1000 Hours Between Oil Changes
Drive Tires
54" - 24x10.50-R12 Radial | 61" - 24x12-R12 Radial
Front Tires
13x6.5-R6 Smooth Tread with Optional Radial Upgrade, No Flats, or Tweels
Wheels Type
Steel
Speed (F/R)
Forward - Up to 9mph | Reverse - Up to 5mph
Features
<!-- -->
Seat
Dymetrol Seat with 360 Degree Floating Seat Platform
Steering Levers
Adjustable Up and Down
Control Panel LCD Display
N/A
Control Panel LED Warning Indicators
N/A
Ignition
Key Switch
Auxiliary Power
12v Outlet Next to Phone Holder
Storage
Phone Holder, Cup Holder, and Deep Storage Tray
Hitch
2" Rear Receiver Standard
Cutting Deck
<!-- -->
Deck Sizes
54", 61"
Deck Depth
6" Deep, Reinforced 7 Gauge Full-Floating Deck
Deck Lift
Foot Operated with Shock Assist.
Deck Adjustment
Magnetic Pin Height Adjustment
Cut Height
1" to 5" with 15 Cut Heights
Blade Spindles
Cast Aluminum, No Maintenance/Sealed Bearings
Parking Brake
Foot Operated
Frame
1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
Measurements
<!-- -->
Width
54” Deck - 55.5” wide | 61” Deck - 62.5” wide
Weight
54” Deck - 1052lbs | 61” Deck - 1095lbs
Length
84"
Height
75” with ROPS up (54” with Folding ROPS down)
Warranty
<!-- -->
Engine Warranty
3 Year
Full Warranty
2 Year / Unlimited Hour Commercial - 120 Day Belt Warranty
Deck Warranty
Lifetime on the leading edge
Hydraulic Drive Warranty
3 Year / 750 Hour
Control Panel Warranty
N/A
