Specs
Engine
<!-- -->
Engine Name
Kawasaki FR691V
Horsepower
23HP
Fuel Capacity
5gal
Drive Line
<!-- -->
Hydraulic Drive
Tuff Torq 400 Series
Hydraulic Drive Torque
Continuous - 118 ft-lb | Max Torque - 295 ft-lb
Hydro Drive Maintenance
200 Hours Between Oil Changes (when heavily used)
Drive Tires
48" , 54" - 22x11-10 Turf Armor
Front Tires
13x6.5-R6 Smooth Tread
Wheels Type
Steel
Speed (F/R)
Forward - Up to 8.5mph | Reverse - Up to 5mph
Features
<!-- -->
Seat
Comfortable, Custom Design
Steering Levers
Adjustable Up and Down
Control Panel LCD Display
Engine Hour Meter - Mower Deck Hour Meter - Tachometer - Low Level Warning Volt Meter - Time Between Oil Change Countdown - Fault Codes
Control Panel LED Warning Indicators
Parking Brake Set - Drive Levers - Operator Present - PTO - Low/Hi Battery Volts - Low Oil PSI
Ignition
Keyless, Personal Code activated
Auxiliary Power
12v Outlet
Storage
Large Cup Holder & Storage Tray
Hitch
N/A
Cutting Deck
<!-- -->
Deck Sizes
48", 54"
Deck Depth
5" Deep, Reinforced 7 Gauge Full-Floating Deck
Deck Lift
Foot Operated with Shock Assist
Deck Adjustment
Change-On-The-Go Precision Deck Height Dial
Cut Height
Quick Adjust Dial from 1" to 4.25" with 12 Cut Heights
Blade Spindles
Cast Aluminum, No Maintenance/Sealed Bearings
Parking Brake
Foot Operated
Frame
1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
Measurements
<!-- -->
Width
48" Deck - 49.5" Wide | 54” Deck - 55.5” Wide
Weight
48" - 782lbs| 54” - 800lbs
Length
81”
Height
46"
Warranty
<!-- -->
Engine Warranty
3 Year
Full Warranty
3 Year / 300 Hour - 120 Day Belt Warranty
Deck Warranty
Lifetime on the leading edge
Hydraulic Drive Warranty
3 Year / 300 Hour
Control Panel Warranty
3 Year
